Dew Point & Humidity Calculator

Calculate the dew point and absolute humidity of your indoor air, check the mould risk on your exterior wall and find out whether airing the room pays off right now.

100% freeNo data storedMagnus formula & DIN 4108-2

Indoor air

°C
%

Outdoor air

°C
%

Exterior wall

Wall surface temperature

The estimate applies to the undisturbed wall area. Room corners, window reveals and walls behind wardrobes are often much colder — measure there if in doubt.

Dew point of indoor air

9.3 °C

20.0 °C · 50 % — If a surface cools down to this temperature, water condenses on it.

Absolute humidity

8.6 g/m³

Max. humidity at room temperature

17.2 g/m³

Humidity is within the recommended range of 40–60%. Recommendation of the German Environment Agency (UBA): 40–60% relative humidity.

Mould risk on the exterior wall

Elevated risk

Surface humidity is between 70 and 80%. Still below the mould criterion but with little margin — corners and spots behind furniture may already be critical.

Surface temperature

14.0 °C

Humidity at the surface

73 %

Mould-critical surface temperature

12.6 °C

80% humidity at the surface

Max. indoor humidity for this wall

55 %

Up to this relative humidity the wall surface stays below 80%.

Temperature factor fRsi

0.70

min. 0.70 per DIN 4108-2

Needed for your values

≥ 0.63

Ventilation: does it pay off right now?

Yes, airing dries the room

Every cubic metre of exchanged air carries about 4.8 g of water outside. Short, intensive airing with windows wide open is effective now.

Indoors

8.6 g/m³

20.0 °C · 50 %

Outdoors

4.1 g/m³

Outdoor dew point: -2.2 °C

Outdoor air warmed to room temperature

3.8 g/m³

rel. humidity after warming: 22 %

Dew point and mould limit curve

At 20.0 °C: if the wall temperature falls below the orange line, the surface becomes mould-critical; below the blue line, condensation forms.

Dew point table

Dew point in °C by room temperature and relative humidity (Magnus formula).

Room temperature40 %50 %60 %70 %
16 °C2.4 °C5.6 °C8.2 °C10.5 °C
18 °C4.2 °C7.4 °C10.1 °C12.4 °C
20 °C6.0 °C9.3 °C12.0 °C14.4 °C
22 °C7.8 °C11.1 °C13.9 °C16.3 °C
24 °C9.6 °C12.9 °C15.8 °C18.2 °C

Basis of calculation & notes

  • Saturation vapour pressure via the Magnus formula over water with the coefficients by Sonntag (1990): E = 6.112 hPa · exp(17.62 · T / (243.12 + T)), as used in the WMO Guide (WMO-No. 8) and by Germany's weather service DWD. Valid from about −45 to +60 °C. Absolute humidity via the gas law with R = 461.5 J/(kg·K).
  • Mould criterion per DIN 4108-2: relative humidity at the component surface should stay below 80%. For this, the standard requires a temperature factor fRsi ≥ 0.70 at 20 °C / 50% indoors and −5 °C outdoors, i.e. a surface temperature of at least 12.6 °C.
  • The surface temperature derived from the U-value is a one-dimensional steady-state estimate with Rsi = 0.25 m²·K/W. Thermal bridges, corners, furniture against the wall and fluctuating temperatures are not taken into account.
  • This calculator does not replace an assessment by experts. If you see mould, notice a musty smell or have health complaints, consult specialists or your doctor.
